Waterproof system
All Miele dishwashers have a safety
valve located on the incoming water
line and a sealed underside with a
water sensor. If a fault occurs, the water
intake is stopped and the drain pump is
activated.
Connection to the water
supply
,
Do not drink water from the
dishwasher!
– The dishwasher can heat its own
water to the temperature required by
the wash program. This allows for
connection of the machine to either a
hot or cold water source. For lowest
energy consumption connect the
dishwasher to a cold water source.
For fastest possible wash times, with
slightly higher energy consumption,
connect the dishwasher to a hot
water source. All programs use hot
water in the rinse cycles.
– The inlet hose is approximately 5 ft.
(1.5m) long.
– A 5 ft. (1.5m) drain extension is
available from Miele.
– The water inlet hose comes
equipped with a 3/4" female hose
thread connector. This can be
directly connected to a water supply
with 3/4" MHT (male hose thread
ends).
– Water pressure: Must be between
4.5 - 145 psi (0.3 - 10 bar).
,
To prevent damage to the
dishwasher, it must only be
connected to a fully vented drainage
system.
,
Do not cut the intake hose. It
contains electrical wiring. If the hose
is cut, the dishwasher will not work.
There will be a water leak and you
could be injured. If the hose is too
long, coil it neatly and place it
behind the machine.
Plumbing
54
