Control panel
a Display
b Delay start button d
with indicator light
c Tab button
d Check/Refill indicators
e Programmes
f Programme selector button
g On button g with indicator light
h Off button o
i In-operation indicator light
This instruction book applies to several different dishwasher models.
The specific dishwasher models below are referred to as follows:
G 1270 = G 1XXX
G 2270 = G 2XXX
The model numbers G 1XXX and G 2XXX used in this book refer to the model
designation specified on the data plate of the appliance (and not the
description on the control panel).
The data plate is located at the top right hand side of the door.
Description of the appliance
6
