Adjusting the upper basket
In order to gain more space for taller
pieces of crockery in the bottom or up
-
per basket, the upper basket can be
adjusted on three levels with 2 cm be
-
tween each level.
The upper basket can also be set at an
angle with one side high and the other
side low. Ensure however, that the bas
-
ket can be inserted smoothly into the
cabinet.
^
Pull out the upper basket.
^
Pull upwards on the levers at either
side of the upper basket.
^
Adjust the basket to the desired
height.
^
Then push the levers securely back
down into position.
Depending on the setting of the upper
basket, the following plate dimensions
can be accommodated.
Model G 6XX
(see data plate for model number)
Upper
basket
level
Plate Ø in cm
Upper
basket
Lower
basket
Top 15 30
Middle 17 28
Bottom 19 26
Model G 8XX
(see data plate for model number)
Upper
basket
level
Plate Ø in cm
Upper
basket
Lower
basket
Top 20 30
Middle 22 28
Bottom 24 26
Loading the dishwasher
24
