Cleaning the condenser unit
Detergent residue, hair and fine fluff
from the dryer can get through the fluff
filters and block the condenser unit.
Dust from the room in which the dryer is
installed can also get into the
condenser unit and cause a blockage.
Check the condenser unit at least
once a year. If the dryer is used
frequently then clean the condenser
unit on a regular basis.
Removing the condenser unit
^
Use the yellow lever supplied to open
the service panel.
^
Insert the lever into the middle of the
gap at the top (see arrow)
^
Now remove the panel by pulling it
diagonally upwards. Then place it to
one side.
^
Turn the lever on the inner cover
downwards to the vertical position.
^ Pull the cover forwards
^ Then remove it by pulling it
diagonally upwards.
^
Turn the lever on the condenser unit
to the vertical position so that the
hook on the lever is no longer in the
groove at the bottom of the
condenser unit housing.
Cleaning and care
25
