Installation
Changing the decor panel
Note: The door should be closed
when installing the decor panel.
On the door lock side remove the 4
screws (3 on the side and 1 under-
neath) and the door strip.
Loosen the remaining 7 screws on
the lower and side decor strips until
the decor panel can be bowed
slightly and taken out.
Reassemble in the reverse order and
tighten the screws.
Decor panel dimensions
(Values in bracket demote tolerances in mm)
Width: 587 mm (- 1)
Height: 602 mm (- 1.5)
Thickness: 1 mm (+ 0.5)
Panels which are thicker than 1.5 mm
require a 4 mm adapter strip available
from Miele specialist dealers or the
Miele Spares Dept.
Note:
When using the adapter strip, the
height of the panel should not exceed
596.5 mm (- 1.5).
24
