Installation
Connecting to an external
drain
The condensed water can be drained
directly if the machine is installed near
a sink or drain outlet.
The machine is equipped with a non-re-
turn valve as standard to prevent water
from flowing back into the machine (eg. if
the machine is connected to a siphon).
Max. drain hose length: (3.0 m) 10 ft
Max. drain height: (1.0 m) 4 ft.
Accessories supplied:
- (2 m) 6 ft drain hose
- Hose clamp
- Hose elbow
Loosen the hose clamp from the
drain outlet at the lower left rear of
the machine and remove the rubber
plug.
Remove the clamp from the plug
and place it over the drain hose.
Push the drain hose onto the drain
outlet. Make sure that the hose is
firmly secured by the hose clamp
and not kinked.
26
