Miele TSB 143 WP User Manual

4. Remove the laundry
30
End of programme/Anti-crease
action
End of programme: lights up in the
time display and the Start/Add laundry
sensor control goes out.
The end of the programme is followed
by the anti-crease phase, which will run
for up to 2hours. The Woollens hand-
care programme does not support the
anti-crease function.
See “Programmable functions“,
“Anti-crease”.
Unloading the drum
Only open the door when the drying
process has finished. Otherwise, the
laundry will not be properly dried
through and cooled down.
 Pull the door open at the side with
the orange marker.
 Remove the laundry.
Items left in the dryer could be dam-
aged by overdrying when the dryer is
used the next time.
Always remove all items from the
drum.
 Turn the programme selector to the 
position.
 Remove the fluff from the 2 fluff filters
in the door opening: see “Cleaning
and care - Fluff filters”.
 Shut the door with a gentle swing.
 Empty the condensed water con-
tainer.

Miele TSB 143 WP Specifications

General

Drum type	Honeycomb
Door color	White
Door hinge	Left
Door style	Opaque door
Cord length	2 m
Drum volume	120 L
Control type	Rotary, Touch
Loading type	Front-load
Drying system	Heat pump
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Delay start (max)	24 h
Cycle time	155 min
Noise level	66 dB
Drying class	A
Drum capacity	7 kg
Refrigerating medium	R290
Number of drying programs	11
Current	13 A
Heat source	Electric
Connected load	1100 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.7 kWh
Energy efficiency scale	A+++ to D
Power consumption (off)	0.3 W
Annual energy consumption	208 kWh

Weight and Dimensions

Depth	643 mm
Width	596 mm
Height	850 mm
Weight	58000 g
Depth with door open	1077 mm
