Miele TSB 143 WP User Manual

Installation
*
I
N
S
T
A
L
L
A
T
I
O
N
*
55
Installation
Levelling the tumble dryer
Ensure that no closeable door, slid-
ing door or an oppositely hinged
door is installed that would hinder
the door of the tumble dryer being
opened in any way.
The tumble dryer must stand perfectly
level to ensure safe and proper opera-
tion.
The screw feet can be adjusted to com-
pensate for unevenness in the floor.
 Risk of fire and explosion due to
damage to the tumble dryer.
The refrigerant is flammable and ex-
plosive.
Do not make any alterations to the
tumble dryer. Take measures to pro-
tect the tumble dryer against dam-
age.
If the tumble dryer is damaged, proceed
as follows:
– Avoid naked flames or anything
which creates a spark.
– Disconnect the tumble dryer from the
electrical supply.
– Air the room where the tumble dryer
is located.
– Contact the Miele Customer Service
Department.
Downtime after installation
 Damage to the tumble dryer by
switching it on too soon.
This can damage the heat pump.
After setting up the tumble dryer wait
for at least one hour before switching
it on.

Miele TSB 143 WP Specifications

General

Drum type	Honeycomb
Door color	White
Door hinge	Left
Door style	Opaque door
Cord length	2 m
Drum volume	120 L
Control type	Rotary, Touch
Loading type	Front-load
Drying system	Heat pump
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Delay start (max)	24 h
Cycle time	155 min
Noise level	66 dB
Drying class	A
Drum capacity	7 kg
Refrigerating medium	R290
Number of drying programs	11
Current	13 A
Heat source	Electric
Connected load	1100 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.7 kWh
Energy efficiency scale	A+++ to D
Power consumption (off)	0.3 W
Annual energy consumption	208 kWh

Weight and Dimensions

Depth	643 mm
Width	596 mm
Height	850 mm
Weight	58000 g
Depth with door open	1077 mm
