Umbau- und Montageanweisung
20 von 86 M.-Nr. 09469886
28.09.2018 Diese Unterlagen dürfen ohne unsere Genehmigung weder vervielfältigt noch Dritten zugänglich gemacht werden. Eigentumsrechte vorbehalten.
DANGER
There is a risk of injury, particularly spinal injuries, as the machine must be placed on its side for fitting.
A The relation of the weight of the machine to the physical strength of the technician must be taken into account.
For machine weight details, see the operating instructions.
Risk of injury due to incorrect fitting
WARNING
Risk of accident if machine tips over.
A The plinth may only be used with Miele machines.
A The plinth must not be used with integrated models or a washer-dryer stack combination.
A Fasten the washing machine to the plinth.
A With a combination with one or more other plinths, individual plinths must be connected together with the
connection pieces.
A With a single machine installation, secure the plinth to the floor with the floor fastening fitting kit,
Mat. no. 06593051.
A At least two plinth feet must be bolted to the floor and at least one of these should be at the rear. Fastening of
two diagonally opposite feet is ideal.
Danger due to unsuitable materials in the plinth drawer
DANGER
A Do not store any inflammable items in the drawer.
NOTE
Wooden parts may swell and/or warp.
A Do not store any damp or wet items in the drawer.
Plinth fitting
Removal of drawer from plinth
A Pull out the drawer fully, see Fig. 2.
A Press the spring catches and at the same time lift the drawer upwards, see Fig. 3.
Fitting the plinth under a tumble dryer
A Empty the condensate container drawer.
A Screw the dryer feet in fully with a pipe wrench.
A Remove the threaded pins from the plinth with a 5mm Allen key (A) and dispose of them, see Fig. 4.
A Fit the 10x40mm threaded pins supplied as far as possible into the threaded bolts (B), see Fig. 4.
WARNING
Risk of crushing fingers if they are trapped between the dryer casing and the threaded pins.
A Do not lift the dryer at the corners.
A Lift the dryer onto the plinth and guide the threaded pins into the openings in the dryer feet, see Fig. 5.
A Fit the sealing strips as shown on the inside of the rear panel, see Fig. 6.
A Loosen the screws on the eccentric cam (1) on the dryer rear panel, see Fig. 7
