Figure 1: Cross Section Peristaltic Inlet
Page (1 / 3)BMP130063/2013484A
Peristaltic Supply
MWF27J8, MWF27Z8
PELLERIN MILNOR CORPORATION
J
PELLERIN MILNOR CORPORATION
AA. Cross section
C. Cold water line
E. Hot water line
F. Hot water to flush the chemical supplies
G. Water and chemical supplies to the shell
H. Hot and cold water to the shell
J. Apply adhesive to the surfaces that connect. Then, tighten the clamp.
4
1
G
FE
C
H
B
B
View A-A
2
3
5
96
