Part II General Information

Field Replaceable Unit 162

4.2 Assembly Explosive View

4.2.1 Monitor Assembly (A0)

No. Order Number Part Name Qty. Remark

115-067739-00 LCD Assembly( Gray/FRU) 1 Include Wi-Fi and 4G module antenna

115-067740-00 LCD Assembly(Blue/FRU) 1 Include Wi-Fi and 4G module antenna
