Specifications and Wiring Diagram
| 30 |
Product specifications are subject to change without prior notice for the improvement of product quality.
Model DWD-M221MB
Dimensions 550(W) X 600(H) X 302(D)
Weight 16.5kg
Water Consumption (Standard course) 25ℓ
Voltage / Frequency 240V / 50Hz
Power Input 1500W
Max. Laundry Load 2.0kg
Operating Water Pressure 98.1kPa~784kPa(1kgf/cm²~8kgf/cm²)
Wiring Diagram
미니_DWD-M221MB(영)_호주향_1도.indd 30 2017-07-04 오후 4:46:38
