11
Strainer (#100mesh)
Strainer (#100mesh)
Heat exchanger
Room temparature thermistor TH21
Gas pipe thermistor TH23
Liquid pipe thermistor TH22
Linear expansion valve
Gas pipe
Flare connection
Gas pipe
PEFY-P06,08,12,15NEMU-E
PEFY-P06,08,12,15NRMU-E
Capacity
Item
ø
12.7(1/2)
ø
12.7(1/2)
R410A
R22
Liquid pipe
ø
6.35(1/4)
ø
6.35(1/4)
ø
15.88(5/8)
ø
9.52(3/8)
ø
15.88(5/8)
ø
15.88(5/8)
ø
9.52(3/8)
ø
9.52(3/8)
R410A
R22
mm <in.>
PEFY-P18NEMU-E
PEFY-P18NRMU-E
PEFY-P24NEMU-E
PEFY-P24NRMU-E
REFRIGERANT SYSTEM DIAGRAM6
