1.2.4 Inside view
(1) Outdoor unit
Models FDCVA151HENR, 201HENR, 251HENR
Model FDCVA302HENR
Control box
Electronic expansion
valve
Receiver
4-way valve
Service valve
Service valve
(Liquid side)
(Heating)
Receiver
(Cooling)
(Gas side)
Compressor
Control box
4way valve
High pressure
switch
(63H1)
Low pressure
sensor
(PSL)
Electronic
expansion valve
(EEVH)
Electronic
expansion valve
(EEVC)
Solenoid valve
(SV1)
Compressor
Service valve
(Liquid side)
Service valve
(Gas side)
