2.1.3 Table of models
2.1.4 Table of system combinations
Notes (1) It is possible to used different models (FDTC,FDT, FDUM, FDEN) when combining indoor units.
(2) Always use the branch piping set (optional) at branches in the refrigerant piping.
(3) If wireless specifications are used, use 1 wireless indoor unit in combination with wired indoor units.
Capacity
Model
Ceiling recessed compact type (FDTC)
Ceiling recessed type (FDT)
Ceiling suspended type (FDEN)
Wall mounted type (FDKN)
Satellite ducted type (FDUM)
Outdoor unit to be combined (FDC)
15 20 25 40 5030
FDCVA302HENR
(3 Horse Power)
FDCVA402HENAR
FDCVA402HESAR
(4 Horse Power)
FDCVA502HENAR
FDCVA502HESAR
(5 Horse Power)
FDCVA602HENAR
FDCVA602HESAR
(6 Horse Power)
FDCVA802HESAR
(8 Horse Power)
FDCVA1002HESAR
(10 Horse Power)






















Indoor unit assembly capacity
Branch pipe set
(Optional)
30+30
40+40
30+50
50+50
20+20+20
30+30+30
20+20+20+20
20+40+40
25+25+50
30+30+40
25+25+25+25
DIS-WA1
DIS-TA1
DIS-TB1
DIS-WB1
DIS-WB1
DIS-TB1
DIS-WA1
x 2set
DIS-WB1
x 1set
DIS-WA1
x 2set
DIS-WB1
x 1set
TypeOutdoor unit
20+20
15+15
FDCVA402HENAR
FDCVA402HESAR
FDCVA302HENR
25+25
20+30
FDCVA502HENAR
FDCVA502HESAR
FDCVA602HENAR
FDCVA602HESAR
FDCVA802HESAR
FDCVA1002HESAR
Twin
Twin
Twin
Twin
Triple
Triple
Triple
Double twin
Double twin
