Cooling power consumption
Heating power consumption
Cooling running current
Heating running current
Inrush current (L.R.A)
2.02/2.02
2.16/2.16
10.4/10.4
11.1/11.1
(220-240V 50Hz/220V 60Hz)
Item
Model
FDCVA302HENAR FDCVA402HENAR FDCVA502HENAR FDCVA602HENAR
kW
A
A
5
2.82/2.82
2.97/2.97
12.3/12.3
13.0/13.0
4.15/4.15
4.19/4.19
18.3/18.3
18.4/18.4
4.64/4.64
4.44/4.44
20.4/20.4
19.5/19.5
Cooling power consumption
Heating power consumption
Cooling running current
Heating running current
Inrush current (L.R.A)
(380-415V 50Hz/380V 60Hz)
Item
Model
FDCVA402HESAR
2.82/2.82
2.97/2.97
4.1/4.3
4.3/4.5
4.15/4.15
4.19/4.19
6.1/6.4
6.1/6.4
5
FDCVA502HESAR
4.64/4.64
4.44/4.44
6.8/7.2
6.5/6.8
FDCVA602HESAR
kW
A
A
(3) Operation chart
The Multi-Type V series is a system that allows for different models and capacities of indoor units to be connected so the individual
operating characteristics of the indoor and outdoor are provided. Use the procedure shown in Item (c) to calculate the combined
operating characteristics.
(a) Operating characteristic of outdoor unit
Cooling power consumption
Heating power consumption
Cooling running current
Heating running current
Inrush current (L.R.A)
(380-415V 50Hz/380V 60Hz)
Item
Model
FDCVA802HESAR
6.34/6.34
6.20/6.20
9.1/9.1
9.0/9.0
8.71/8.71
7.75/7.75
12.7/12.7
11.4/11.4
FDCVA1002HESAR
kW
A
A
5
Note (1) This packaged air-conditioner is manufactured and tested in conformity with the following standard.
ISO-T1 “UNITARY AIR-CONDITIONERS”
(b) Operating characteristic of indoor unit
FDTC Series
(220-240V 50Hz/220V 60Hz)
Notes (1) This packaged air-conditioner is manufactured and tested in conformity with the following standard.
ISO-T1 “UNITARY AIR-CONDITIONERS”
(2) The values shown in the above table are common to both cooling and heating operations.
Model
Item
FDTCA151R FDTCA201R
Cooling power consumption
kW
0.046-0.046/0.046
Heating power consumption 0.046-0.046/0.046
Cooling running current
A
0.15-0.14/0.15
Heating running current 0.15-0.14/0.15
Model
Item
FDTA151R FDTA201R FDTA251R FDTA301R
FDTA401R*
FDTA501R
Cooling power consumption
kW
0.064-0.075/0.079 0.072-0.081/0.090 0.129-0.146
0.150-0.150/0.150
Heating power consumption 0.061-0.071/0.076 0.068-0.078/0.086 0.123-0.140
0.146-0.146/0.146
Cooling running current
A
0.32-0.34/0.42 0.37-0.41/0.42 0.56-0.62 0.48-0.44/0.48
Heating running current 0.30-0.33/0.40 0.36-0.39/0.40 0.54-0.59
0.47-0.43/0.47
FDT Series (220-240V 50Hz/220V 60Hz)
* Not available in 60Hz
Model
Item
FDENA151R FDENA201R FDENA251R FDENA301R FDENA401R FDENA501R
Cooling power consumption
kW
0.054-0.061/0.061 0.100-0.110/0.110
0.142-0.161/0.166 0.166-0.185/0.200
Heating power consumption 0.050-0.056/0.056 0.091-0.101/0.101
0.130-0.147/0.152 0.152-0.169/0.183
Cooling running current
A
0.25-0.26/0.29 0.46-0.48/0.50 0.65-0.67/0.77 0.77-0.78/0.90
Heating running current 0.23-0.24/0.26 0.42-0.44/0.46 0.59-0.62/0.70 0.70-0.72/0.83
FDEN Series (220-240V 50Hz/220V 60Hz)
