・This munual is for instaration of an indoor unit and an outdoor air processing unit (FDU-F).
・This manual is for the installation of an indoor unit.
For electrical wiring work (Indoor), refer to the electrical wiring work installation manual. For
remote control installation, refer to the installation manual attached to a remote control. For
wireless kit installation, refer to the installation manual attached to a wireless kit. For electrical
wiring work (Outdoor) and refrigerant pipe work installation for outdoor unit, refer to the installation
manual attached to an outdoor unit.
t5IF total connection capacity of the other air-conditioning units and the outdoor air processing units
must be from 50% to 100% (the total includes the outdoor air processing unit).
The connection capacity of the outdoor air processing unit must not exceed 30% of the capacity of
the outdoor unit.
t4JOHMF outdoor air processing unit can be used alone. The connection capacity of the outdoor air
processing unit must be from 50% to 100% of the total capacity of the outdoor unit.
Maximum number of outdoor air processing units that can be connected to the outdoor unit is
2units.
t$apacities of the suction air processing units can be calculated with the forllowing formulas.
FDU850FKXEZ1 = 90, FDU1100FKXEZ1 = 140
The case of FDU-F
SAFETY PRECAUTIONS
WARNING
●
in order to protect yourself.
●The precautionary items mentioned below are distinguished into two levels, and .
: Wrong installation would cause serious consequences such as injuries or death.
: Wrong installation might cause serious consequences depending on circumstances.
Both mentions the important items to protect your health and safety so strictly follow them by any means.
●The meanings of “Marks” used here are as shown on the right:
●
cleaning, operation method and temperature setting method) with user’s manual of this unit.
Ask your customers to keep this installation manual together with the user’s manual. Also, ask them to hand
over the user’s manual to the new user when the owner is changed.
●
Installation should be performed by the specialist.
of the unit.
●
Install the system correctly according to these installation manuals.
●
Checkthedensityreferedbythefoumula (accordancewithISO5149).
Ifthedensityexceedsthelimitdensity, please consultthe dealer andinstallatetheventilationsystem.
●
●
Ventilate the working area well in case the refrigerant leaks during installation.
●
Install the unit in a location that can hold heavy weight.
Improper installation may cause the unit to fall leading to accidents.
●
Install the unit properly in order to be able to withstand strong winds such as typhoons, and earthquakes.
Improper installation may cause the unit to fall leading to accidents.
●
Do not mix air in to the cooling cycle on installation or removal of the air-conditioner.
If air is mixed in, the pressure in the cooling cycle will rise abnormally and may cause explosion and injuries.
●
●
in order not to apply unexpected stress on the terminal.
●
Arrange the electrical wires in the control box properly to prevent them from rising. Fit the lid of the
services panel property.
●
Check for refrigerant gas leakage after installation is completed.
If the refrigerant gas leaks into the house and comes in contact with a fan heater, a stove, or an oven, toxic gas is produced.
●
Using existing parts (R22) could cause the unit failure and serious accident due to explosion of the cooling cycle.
●
●
can occur.
cause the corrosion of the indoor unit and a resultant unit failure or refrigerant leak.
●
Connect the pipes for refrigeration circuit securely in installation work before compressor is operated.
If the compressor is operated when the service valve is open without connecting the pipe, it could cause explosion and injuries due
to abnormal high pressure in the system.
●
Stop the compressor before removing the pipe after shutting the service valve on pump down work.
If the pipe is removed when the compressor is in operation with the service valve open, air would be mixed in the refrigeration circuit
and it could cause explosion and injuries due to abnormal high pressure in the cooling cycle.
●
●
Do not repair by yourself. And consult with the dealer about repair.
●
Consult the dealer or a specialist about removal of the air-conditioner.
●
Turn off the power source during servicing or inspection work.
If the power is supplied during servicing or inspection work, it could cause electric shock and injury by the operating fan.
●
Do not run the unit when the panel or protection guard are taken off.
Touching the rotating equipment, hot surface, or high voltage section could cause an injury to be caught in the machine, to get
burned, or electric shock.
●
Shut off the power before electrical wiring work.
It could cause electric shock, unit failure and improper running.
④Preparation before installation
②Selection of installation location for the indoor unit
①4FMFDUUIFTVJUBCMFBSFBTUPJOTUBMMUIFVOJUVOEFSapproval of the user.
・
a circulator if the ceiling height is over 3m to avoid warm air being accumulated on the ceiling.
・Areas where there is enough space to install and service.
・Areas where it can be drained properly. Areas where drain pipe descending slope can be
taken.
・
・
・Areas where the supply air does not short-circuit.
・
・Areas not exposed to direct sunlight.
・Areas where dew point is lower than around 28°C and relative humidity is lower than 80%.
This indoor unit is tested under the condition of JI4 (Japan Industrial 4tandard) high humidity
drop if the air conditioner is operated under the severer condition than mentioned above.
If there is a possibility to use it under such a condition, attach additional insulation of 10 to
20mm thick for entire surface of indoor unit, refrigeration pipe and drain pipe.
・Areas where TV and radio stays away more than 1m. (It could cause jamming and noise.)
・Areas where any items which will be damaged by getting wet are not placed such as food,
table wares, server, or medical equipment under the unit.
・
・Areas where not exposed to oil mist, powder and/or steam directly such as above fryer.
・
operation.
(A beam from lighting device sometimes affects the infrared receiver for the wireless remote
control and the air conditioner might not work properly.)
・When operating the suction air processing unit independently, it operates in the outdoor air
processing mode.
Blowout temperatures are not same at the standard unit operation and the outdoor air
processing mode operations.
4JODF the temperatures become higher during cooling or lower during heating, take care of
the direction of blowout outlet.
Avoid directing the blowout outlet to the space where people are present.
②Check if the place where the air-conditioner is installed can hold the weight of the unit. If it is
not able to hold, reinforce the structure with boards and beams strong enough to hold it. If the
strength is not enough, it could cause injury due to unit falling.
●Make installation altitude over 2.5m.
(Indoor Unit)
4FMFDUFJUIFSPGUXPDBTFTUPLFFQTQBDFGPSJOTUBMMation and services.
Notes (a) There must not be obstacle to draw out fan motor. ( marked area)
(b) Install refrigerant pipe, drain pipe, and wiring so as not to cross marked area.
●If suspension bolt becomes longer, do reinforcement of earthquake resistant.
○For grid ceiling
When the suspension bolt length is over 500mm, or the gap between the ceiling and roof is
over 700mm, apply earthquake resistant brace to the bolt.
○In case the unit is hanged directly from the slab and is installed on the ceiling plane which
has enough strength.
When suspension bolt length is over 1000mm, apply the earthquake resistant brace to the bolt.
●Prepare four (4) sets of suspension bolt, nut and spring washer (M10) on site.
Never do it under any circumstances. Always do it according to the instruction.
○This model is high static ducted type air-conditioning unit.Therefore, do not use this model for direct
blow type air-conditioning unit.
4VTQFOTJPO#PMU-PDation
○ Adhere to the
measurements given
below for the length of
the suspension bolts.
4VTQFOTJPO
bolt (M10)
Return duct
Air supply duct
Unit
Under
50 mm
UNIT: mm
4JOHMe type
Multi type
FDU-F
A
B
C
-
45, 56
-
786
472
135
71
71, 90
650
986
472
135
100-140
112-160
1100
1720
725
180
Multi type
4JOHMFUZQF
112-160
100-140
Pipe locations UNIT: mm
Multi type
4JOHMFUZQF
45-90
FDU-F 1100
FDU-F 650
71
CAUTION
CAUTION
①Before installation
●Install correctly according to the installation manual.
●
○ ○1JQFT8JSFT4NBMMQBSUT○Accessory items
Accessory item
4JOHMFUZQF
Multi type
FDU-F
A
B
4J[FPGJOTQFDUJPOIPMF
-
45, 56
-
1100
71
71, 90
650
1300
100-140
112-160
1100
1720
725
(For natural drainage)
drain pipe connection VP20 (PVC pipe)
drain pipe connection
(PVC pipe) (Drain hose VP25)
510
635
468
405
467
187
145
95
29
471
413
203
174
104
29
467
Refrigerant liquid pipe
Refrigerant gas pipe
(For natural drainage)
drain pipe connection VP20 (PVC pipe)
drain pipe connection
(PVC pipe) (Drain hose VP25)
Refrigerant gas pipe
Refrigerant liquid pipe
(Case 2) From bottom of unit
(Case 1) From side of unit
600
or more
100
or more
100
or more
20
or more
20
or more
A
B
Inspection
hole
Note (a)
Note (b)
100-200
370
150-
200
Ceiling
4MBC
Inspection
hole
(450x450)
1000 or more
UNIT: mm
UNIT: mm
UNIT: mm
620
DUCT CONNECTED HIGH STATIC PRESSURE AIR-CONDITIONING
(OUTDOOR AIR PROCESSING FDU-F) UNIT INSTALLATION MANUAL
4QBDFGPSJOTUBMMation and service
●
Perform earth wiring surely.
Do not connect the earth wiring to the gas pipe, water pipe, lightning rod and telephone earth wiring. Improper earth could
cuit.
●
Earth leakage breaker must be installed.
●
Use the circuit breaker of correct capacity. Circuit breaker should be the one that disconnect all
poles under over current.
●
Do not use any materials other than a fuse of correct capacity where a fuse should be used.
●
●
●
●
Do not use the indoor unit at the place where water splashes such as laundry.
●
Do not use the indoor unit for a special purpose such as food storage, cooling for precision
instrument, preservation of animals, plants, and a work of art.
It could cause the damage of the items.
●
Do not install nor use the system near equipments which generate electromagnetic wave or high harmonics.
Equipments like inverter equipment, private power generator, high-frequency medical equipment, or telecommunication
●
Do not install the remote control at the direct sunlight.
It could cause breakdown or deformation of the remote control.
●
Do not install the indoor unit at the place listed below.
·
Place where the substances which affect the air-conditioner are generated
· Places exposed to oil mist or steam directly.
· On vehicles and ships
· Places where machinery which generates high harmonics is used.
●
Do not install the indoor unit in the locations listed below (Be sure to install the indoor unit
according to the installation manual for each model because each indoor unit has each limitation)
· -PDations with any obstacles which can prevent inlet and outlet air of the unit
· -PDations where the infrared receiver is exposed to the direct sunlight or the strong light beam. (in case of the
· -PDations where an equipment affected by high harmonics is placed. (TV set or radio receiver is placed within 5m)
· -PDations where drainage cannot run off safely.
It can affect performance or function and etc.
.
●
Do not put any valuables which will break down by getting wet under the air-conditioner.
Condensation could drop when the relative humidity is higher than 80% or drain pipe is clogged, and it damages user’s belongings.
●
Do not use the base frame for the outdoor unit which is corroded or damaged after a long period of use.
It could cause the unit falling down and injury.
●
Pay attention not to damage the drain pan by weld sputter when brazing work is done near the unit.
*GTQVUUFSFOUFSFEJOUPUIFVOJUEVSJOHCSB[JOHXPSL, it could cause damage (pinhole) of drain pan and leakage of water.
To avoid damaging, keep the indoor unit packed or cover the indoor unit.
●
Install the drain pipe to drain the water surely according to the installation manual.
Improper connection of the drain pipe may cause dropping water into room and damaging user’s belongings.
●
Do not share the drain pipe for indoor unit and GHP (Gas Heat Pump system) outdoor unit.
user’s health and safety.
●
Be sure to perform air tightness test by pressurizing with nitrogen gas after completed refrigerant piping work.
If the density of refrigerant exceeds the limit in the event of refrigerant leakage in the small room, lack of oxygen can
occur, which can cause serious accidents.
●
For drain pipe installation, be sure to make descending slope of greater than 1/100, not to make traps,
and not to make air-bleeding.
Check if the drainage is correctly done during commissioning and ensure the space for inspection and maintenance.
●
Ensure the insulation on the pipes for refrigeration circuit so as not to condense water.
●
Do not install the outdoor unit where is likely to be a nest for insects and small animals.
Insects and small animals could come into the electronic compon
keep the surroundings clean.
●
Pay extra attention, carrying the unit by hand.
Carry the unit with 2 people if it is heavier than 20kg. Do not use the plastic straps but the grabbing place, moving the unit
●
Make sure to dispose of the packaging material.
-Faving the materials may cause injury as metals like nail and woods are used in the package.
●
It may cause the breakdown of the system due to clogging of the heat exchanger.
●
Do not touch any button with wet hands.
It could cause electric shock.
●
Do not touch the refrigerant piping with bare hands when in operation.
The pipe during operation would become very hot or cold according to the operating condition, and it could cause a burn or frostbite.
●
Do not clean up the air-conditioner with water.
It could cause electric shock.
●
Do not turn off the power source immediately after stopping the operation.
Be sure to wait for more than 5 minutes. Otherwise it could cause water leakage or breakdown.
●
Do not control the operation with the circuit breaker.
· Places where cosmetics or special sprays are
frequently used.
· Highly salted area such as beach.
· Heavy snow area
· Places where the system is affected by
smoke from a chimney.
· Altitude over 1000m
CAUTION
③
Cautions for the handling and installation place of outdoor air processing unit
①
stop with the thermostat based on the value of sensor A and the setting temperature by the remote control.
Remote control’s setting temperature indicates the outdoor air temperature that controls the start and stop of operation
by the thermostat.
When the thermostat is turned off, the operation is changed to the fan mode so that the outdoor air is blown out
directly into the room. For example if the remote control is set to 22°C in cooling operation, and if the outdoor air
temperature is 22°C or lower at that time, the unit will go into fan operation.
②
When there is a difference between the air-conditioning temperature in the room during cooling operation and the tempera-
ture of air blown out from the outdoor air processing unit, dewing water may drip from the unit.To prevent the dewing, provide
③
4JODF the air blow outlet on the outdoor air processing unit may blow out the outdoor air directly, orient the outlet in such a
way that it will not blow air directly to persons in the room.
④
4JODF the unit controls the thermostat start and stop by monitoring the outdoor air temperature, it is prohibited to monitor the room
temperature by means of the room temperature monitoring by changing the thermostat setting at the remote control side and the
optional remote thermistor. Otherwise, dewing water may drip from the unit at lower outdoor air temperatures during cooling operation.
⑤
Install the remote control of the outdoor air processing unit at a place closer to the administrator to avoid the end user from
using the remote control.
installation place of the remote control for the outdoor air processing unit and the position of air blow outlet.
Duct Duct
Outdoor air blind
Outdoor air
4FOTPS"
Unit body
Accessory parts are stored
inside this suction side.
For refrigerant pipe For drain pipe
Pipe cover
(big)
Pipe cover
(small)
Elbow
(Multi only)
Pipe cover
(big)
Pipe cover
(small)
Drain hose Hose clamp4USap
1 1 4 1 1 1 1
For heat insulation
of gas pipe
For heat insulation
of liquid tube
For pipe
For hanging
Flat washer
(M10)
8
For unit
hanging
For drain hose
mounting
1
For drain pipe
connecting
For heat insulation
of drain socket
For heat insulation
of drain socket
For drain pipe
connecting
-
-
To Next Page
Need help?
General
