123
-
(10) Checking Operation Data
Operation data can be checked with remote controller unit operation.
1 Press the
CHECK button.
The display change from “
SELECT ITEM”
“
SET"
“OPERATION DATA
”.
2 Press the SET button while “OPERATION DATA
” is displayed.
3 The display will change to “I/U No. 00
” (blinking indication).
Select the indoor unit number you want to have data displayed with the
button.
(When only one indoor unit connected, the indoor unit number displayed on the screen will not change.)
4 Determine the indoor unit number will the SET button.
(The indoor unit number changes from blinking indication to continuous indication.)
“DATA LOADING” (A blinking indication appears while data is loaded)
“OPERATION DATA
” appears and data number 01 is displayed.
5 Upon operation of the
button, the current operation data is displayed in order from Data number 01.
The items displayed are as follows:
* Depending on models, the items that do not have corresponding data are not displayed.
6 To display the data of a different indoor unit, press the
AIR CON No. button, which allows you to go back to the indoor unit
selection screen.
7 Pressing the ON/OFF button will stop displaying data.
Number
01
02
03
04
05
07
11
21
22
23
24
27
28
29
31
32
34
35
36
37
(Operation mode)
(Indoor unit heat exchanger temperature 1)
(Indoor unit heat exchanger temperature 2)
(Indoor unit fan speed)
(Indoor unit operation hours)
(Outside air temperature)
(Outdoor unit heat exchanger temperature 1)
(Outdoor unit heat exchanger temperature 2)
(Discharge pipe temperature)
(Outdoor unit fan speed)
(Compressor operation hours)
(Expansion valve opening 1)
SET TEMP
RETURN AIR
I/U HEAT EXCH 1
I/U HEAT EXCH 2
I/U FAN
TOTAL I/U RAN
OUTDOOR
O/U HEAT EXCH 1
O/U HEAT EXCH 2
COMP HERTZ
DISCHARGE
DOME BOTTOM
CT
O/U FAN
SILENT MODE ON/OFF
63H1 ON/OFF
DEFROST ON/OFF
TOTAL COMP RUN
EEV 1
Data item
Pressing the RESET button during remote controller unit operation will undo your last operation and allow you to go back to
the previous screen.
To Next Page
