Mitsubishi Heavy Industries HSB100 Technical Manual

-
6
-
Technical data
'19 • HM-T-340
Technical specifications
Technical specifi cations
Specifications
I
ndoor units
All in one type
Model HMA60-S HMA100-S
General conditions
Power source
230V AC / 400V 3NAC
50 Hz
Max current (A) 45 for 230V single-phase / 20 for 400V three-phase
Recommended fuse (A) 50 for 230V single-phase / 25 for 400V three-phase
Wire size 6 × 10 mm
2
Power source deviation (%) -1.5 ÷ +10
Power factor 0.99
Pipe size refrigerant (ref) Gas piping: OD12.7, liquid: OD6.35 (1/2”; 1/4”) Gas piping: OD15.88, liquid: OD9.52 (5/8”; 3/8”)
Indoor unit (split type, hydrounit)
Immersion heater Max 9 kW (4.5kW for single phase 230V)
Capacity steps heater 3 (1.5, 3.0, 4.5kW) for single-phase 230V , 3 (3,6,9 kW) for three-phase 400V
Circulating pump Wilo Yonos Para
Pump control sanitary hot water Variable
Pump capacity, max head 76 kPa (external)
Pump capacity, max flow 4 m
3
/h
Pump power 5-75W
Pump efficiency, max EEI≤0.21
Heat exchanger
2 HP
Plate type Alfa Laval, ACH-18-52H
3.5 HP
Plate type Alfa Laval, ACH-30EQ-80H
Heat exchanger size 0.9 m
2
1.8 m
2
Pressure transmitter 0-4.6 MPa, deviation ±3%
Water strainer system 0.6 mm
2
Filter drier refrigeration system Bi-flow 083
Emergency thermostat 5-77 °C
Thermal cut-off 98 (-8) °C
Motor valves 2 × 3-way, ball type
Actuator 230V 50 Hz, 8s/60°
Safety relief valve system 0.3 MPa
Manometer gauge 0-0.4 MPa
Expansion vessel 10 ℓ
IP grade IP21
Volume total 180 ℓ ±5%
Volume coil 4.8 ℓ
Area coil 1.6 m
2
Material coil Steel untreated S235JR
Material tank Enamelled steel S235JR 3.0 mm
Cabinet
Top/side/front bottom EN10130 DC01
Back DX51D+Z275
