9
-
φ9.52（3／8"）（ Flare）
Content
C Pipe／cable draw-out hole
D
E Anchor bolt hole
Drain discharge hole
Symbol
B
A Service valve connection（Gas side）
M10-12×4 places
φ20×5 places
Service valve connection（Liquid side）
φ6.35（1／4"）（ Flare）
Unit:mm
145
520
290
2-R
2-12X16
Slot hole
L2
Inlet
Outlet
Inlet
L3
L1
Service
space
( )
L4
Terminal block
L2
L3
L4
L1
100
100
250
Open
Ｉ Ⅱ
Open
250
80
280
Ⅲ
280
Open
80
75
Examples
Size
installation
Ⅳ
180
Open
80
Open
Minimum installation space
A
C
B
D E
E
E
E
93 42.5
640
800
89 510 201
327.3
83.5
290
43.5
327.3
50.6
12
24.3312.514.8
71.2
17.9
40°
40°
33.5148.4
12.4
351.6
38.6
90.6
520.6 161
35.6
Notes
（ 1） The unit must not be surrounded by walls on the four sides.
（ 2） The unit must be fixed with anchor bolts. An anchor bolt must not
protrude more than 15mm.
（ 3） If the unit is installed in the location where there is a possibility of
strong winds, place the unit such that the direction of air from the
outlet gets perpendicular to the wind direction.
（ 4） Leave 200mm or more space above the unit.
（ 5） The wall height on the outlet side should be 1200mm or less.
（ 6） The model name label is attached on the right side of the unit.
Center of gravity
Center of gravity
(2) Outdoor units
Models SRC20ZSX-S, 25ZSX-S, 35ZSX-S
RCT000Z019
