'09•SRK-DB-087D
(b)
Sleep timer operation
(11)
Timer operation
(a)
Comfort start-up (ON timer operation)
(c)
OFF timer operation
(14)
Airflow range setting
(a)
Setting
(i) If the air-conditioner is running, press the ON/OFF button to stop.
(ii)
Press the AIR FLOW U/D (UP/DOWN) button and the
AIR FLOW L/R (LEFT/RIGHT) button together for 5 seconds
or more.
(iii)
Setting the airflow range.
(iv)
Press the ON/OFF button.
Airflow range Airflow rangeAirflow range
(Left end installation) (Center installation) (Right end installation)
(Center installation)
L/R
L/R
(Right end installation) (Left end installation)
The unit starts the operation 5 to 60 minutes earlier so that the room can approach optimum temperature at ON timer.
The OFF timer can be set at a specific time (in 10-minute units) within a 24-hour period.
(d)
Weekly timer operation
Up to 4 programs with timer operation (ON timer / OFF timer) are available for each day of the week.
Take the air-conditioner location into account and adjust the left/right airflow range to maximize air-conditioning.
display
( i ), (
iv
)
(
ii
), (
iii
)
(
ii
)
MENU
'09•SRK-DB-087D
(b)
Sleep timer operation
(11)
Timer operation
(a)
Comfort start-up (ON timer operation)
(c)
OFF timer operation
(14)
Airflow range setting
(a)
Setting
(i) If the air-conditioner is running, press the ON/OFF button to stop.
(ii)
Press the AIR FLOW U/D (UP/DOWN) button and the
AIR FLOW L/R (LEFT/RIGHT) button together for 5 seconds
or more.
(iii)
Setting the airflow range.
(iv)
Press the ON/OFF button.
Airflow range Airflow rangeAirflow range
(Left end installation) (Center installation) (Right end installation)
(Center installation)
L/R
L/R
(Right end installation) (Left end installation)
The unit starts the operation 5 to 60 minutes earlier so that the room can approach optimum temperature at ON timer.
The OFF timer can be set at a specific time (in 10-minute units) within a 24-hour period.
(d)
Weekly timer operation
Up to 4 programs with timer operation (ON timer / OFF timer) are available for each day of the week.
Take the air-conditioner location into account and adjust the left/right airflow range to maximize air-conditioning.
display
(12)
Silent operation
When the silent operation is set, the unit operates by dropping the outdoor fan speed and the compressor speed.
(13)
Night setback operation
When the night setback operation is set, the heating operation starts with the setting temperature at 10
℃
.
Outdoor fan speed
(Upper limit)
Compressor speed
(Upper limit)
Cooling Heating Cooling Heating Cooling Heating
Cooling Heating
SRK20ZSX-S SRK25ZSX-S SRK35ZSX-S SRK50ZSX-S
4th speed
18 rps
4th speed
26 rps
4th speed
24 rps
5th speed
32 rps
5th speed
36 rps
6th speed
44 rps
5th speed
52 rps
5th speed
52 rps
Cooling Heating
SRK60ZSX-S
5th speed
52 rps
5th speed
52 rps
