Defective diodes or stator See Bench Test in
ALTERNATOR article
Battery Does Loose or worn drive belt Check alternator drive
Stay Charged belt tension and
condition. See
Belt Adjustment in
appropriate TUNE-UP
article in the
TUNE-UP section
Loose or corroded battery Check all charging
connections system connections
Loose alternator connections Check all charging
system connections
Defective alternator or See On-Vehicle Tests
battery and Bench Tests in
ALTERNATOR article
Add-on electrical accessories Install larger
exceeding alternator capacity alternator
Battery Defective battery Check alternator
Overcharged- output and repair as
Uses Too Much necessary
Water
Defective alternator See On-Vehicle Test and
Bench Tests in
ALTERNATOR article
Excessive alternator voltage Check alternator output
and repair as necessary
IGNITION SYSTEM TROUBLE SHOOTING
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.
Ignition Secondary Trouble Shooting Chart
START: Visually inspect Spark Plug Wires, Coil Wires,
Plug Wire Boots, Rotor, and Distributor Cap for
signs of damage.
OK
NOT OK
* To test secondary ignition
* Repair or replace
system, modify a Spark Plug
damaged components
by attaching a ground wire
as necessary
to the body of the plug and
To Next Page
