ignition switch
Open circuit between Repair circuit
ignition switch and
starter solenoid
Engine Runs Fuel lines leaking or Tighten fitting,
Rough clogged remove restriction
Initial timing incorrect Reset ignition timing
see ENGINE PERFORMANCE
Centrifugal advance Repair distributor
malfunction advance
Defective spark plugs or Replace plugs or plug
wiring wiring
Component Failure Spark arc-over on cap, Replace cap, rotor or
rotor or coil or coil
Defective pick-up coil Replace pick-up coil
Defective ignition coil Replace ignition coil
Defective vacuum unit Replace vacuum unit
Defective control module Replace control module
BASIC ELECTRONIC IGNITION TROUBLE SHOOTING
CHARTS - USING OSCILLOSCOPE PATTERNS
CONDITION POSSIBLE CAUSE CORRECTION
Firing Voltage Retarded ignition timing Reset ignition
Lines are the Same, timing, see ENGINE
but Abnormally High PERFORMANCE section
Fuel mixture too lean Readjust carburetor,
see ENGINE PERFORMANCE
High resistance in coil Replace coil wire
wire
Corrosion in coil tower Clean and/or replace
terminal coil
Corrosion in distributor Clean and/or replace
coil terminal distributor cap
Firing Voltage Fuel mixture too rich Readjust carburetor,
Lines are the Same see ENGINE PERFORMANCE
but Abnormally Low
Breaks in coil wire causing Replace coil wire
arcing
Cracked coil tower causing Replace coil
arcing
Low coil output Replace coil
Low engine compression Determine cause and
