8
1. Slide the seat all the way to the rear by pulling up on the sliding
lever located under the bottom of the seat and pushing to the back.
2. Pull up on the front edge of the bottom seat cushion and raise it up.
Then lift the back side of the bottom seat cushion up and flip it over
toward the front side as you rotate the bottom seat cushion into the
foot well area.
3. Once the seat cushion is flipped forward, slide the lever (A) which
is now visible, forward into the “seat flat” position to lock the seats
down.
1. Remove Headrests from storage hook on folded seat cushion.
2. Raise the seatback until it locks into place.
3. Make sure the seat belt buckles are up (D) (Figure 3) and gently
lift the seat cushion and fold it back into position making sure the
hook (E) slides below the seatback bottom. Press down on the seat
cushion to lock into place.
4. Replace headrests.
1. Remove the head restraints.
2. Pull up the strap (A), then fold the seatback forward.
3. To return, pull the strap (B), then raise the seatback until it locks
securely into place.
FOLDING AND STOWING THE SECOND AND THIRD ROW SEAT (if equipped)
Folding the second row seats Unfolding the second row seats
Folding the third row seat
A
B
C
A
4. Remove the headrests by pushing the button on the headrest post
and then lifting up on the headrest simultaneously. Place the
headrest out of the way. (The middle headrest can remain in the
lowest position).
5. Now pull the lever on the top of the backrest (B) and lower the seat
forward so it lays flat.
6. Grab the headrest and face it forward. Find the slit on the bottom
rear of the headrest and place it on the metal hook located on the
middle part of the folded seat cushion (C). Place your other hand on
the back of the headrest and gently push it down until you hear and
or feel it lock into place.
D
E
Figure 3
