ELECTRICAL SYSTEM
3-5
(OFF)
(ON)
(START)
B
M
S
203561A
Connection Chart
Major Electrical Components
Starter Switch (with Anti-Restart Lock)
This switch has a built-in anti-restart lock, so the key
cannot be turned from (ON) to (START) position
while the engine is running.
Key
position
Terminal
B
M
S
Component
Fuse box, battery,
alternator
Fuse box, fuel-cut
solenoid
Starter, neutral switch
(powershift
transmission models)
(OFF)
{
(ON)
{
{
(START)
{
{
{
