OUTLINES AND DIMENSIONS
Handle for moving
Side Air Intake
Front piping cover
Rear piping cover
Air intake
Rear Air Intake
Handle for moving
Handle for moving
Service panel
Handle for moving
Air Discharge
Rear Air Intake
Side Air Intake
14514522030 145
81 219
71
71
Bottom piping hole
(Knockout)
Drain hole
5-:33
600175 175
28 370
70
56
42
56
37
19
53
417
330
Installation Feet
2-12%36 Oval holes
(Foundation Bolt M10)
2-U Shaped notched holes
(Foundation Bolt M10)
30
920
322
635
371
950
23
1350
+1 423
+1 507
Handle for moving
1
2
( )
Left····· For the power supply
Center·····For the transmission line
Right····· For concentration control
Terminal connection
Ground for the transmission line
Ground for concentration control
Ground for the power supply
Over
Over
Over
Over
Less than
Piping and wiring connections
can be made from 4 directions:
front, right, rear and below.
4 PIPING-WIRING DIRECTIONS
3 FOUNDATION BOLTS2 SERVICE SPACE
1 FREE SPACE (Around the unit)
Please secure the unit firmly
with 4 foundation (M10) bolts.
(Bolts and washers must be
purchased locally.)
<Foundation bolt height>
Dimensions of space needed
for service access are
shown in the below diagram.
The diagram below shows a
basic example.
Explantion of particular details is
given in the installation manuals etc.
FREE
Over 10mm
Over 10mm
Over 150mm
Over 1000mm
30
FOUNDATION
10
500
500
150
Service space
Piping Knockout Hole Details
Example of Notes
···
Refrigerant GAS pipe connction (FLARE):15.88 (5/8 inch)
···
Refrigerant LIQUID pipe connection (FLARE): 9.52 (3/8 inch)
+1
···
Indication of STOP VALVE connection location.
637323
5527
92
65
4045
Power supply wiring hole
(2-:27Knockout)
Rear trunking hole
(Knockout)
Rear piping hole
(Knockout)
:92
922723
6373
4075
92
5519
Power supply wiring hole
(2-:27Knockout)
Right trunking hole
(Knockout)
Right piping hole
(Knockout)
:92
637323
5527
40 45
65
92
Power supply wiring hole
(2-:27Knockout)
Front trunking hole
(Knockout)
Front piping hole
(Knockout)
:92
PUMY-P100YHM PUMY-P100YHM1
PUMY-P125YHM PUMY-P125YHM1
PUMY-P140YHM PUMY-P140YHM1
Unit : mm
