3 - 42 3 - 42
MELSEC-Q
3 SPECIFICATIONS
3.7 List of GX Developer Setting Items for the QD51 (-R24)
The following table shows a list of parameter setting items set using GX Developer.
Parameter Setting Item Parameter Contents Setting Contents Explanation Section
Type
Model name
Number of points
Header X/Y
I/O Allocation Setting
Allocates I/O in the QD51 (-R24),
and enables the following switch
settings.
Detailed settings
Section 5.6.1
Switch 1 Setting switch
Switch 2 Mode setting switch
Switch 3
Switch 4
Switch Settings
Switch 5
Not used (Set 0000H)
Section 5.6.2
Interrupt pointer header No.
CPU Side
Number of interrupt pointers
Header I/O No.
Interrupt Pointer Settings
Carries out settings in order to
execute an interrupt program.
Intelligent
module Side
Header SI No.
Section 5.6.3
Multiple CPU Settings
Set when using a Multiple CPU
system.
Number of CPU's , etc.
Refer to QCPU User's Manual
(Multiple CPU System)
