3
OCH688A
Outdoor unit model
SUZ-KA18
NA(H)2
SUZ-KA24
NA(H)2
SUZ-KA30
NA(H)2
SUZ-KA36
NA(H)2
Power supply V , phase , Hz 208/230 , 1 , 60
Max. fuse size (time delay) A 15 20
Min. circuit ampacity A 14 17
Fan motor F.L.A 0.67 1.00
Compressor
Model
SNB130FQBMT SNB220FQGM1T
R.L.A 10.0 13.0
L.R.A 12.5 16.0
Refrigeration oil oz. (Model) 11.8(FV50S) 15.6(FV50S)
Refrigerant control Linear expansion valve
Sound level
*
1
Cooling dB(A) 54 55
Heating dB(A) 55
Defrost method Reverse cycle
Dimensions
Win 34-5/8
D in 33-1/16
Hin 13
Weight Ib 127 129
([WHUQDO¿QLVK Munsell 3Y 7.8/1.1
Control voltage
(by built-in transformer)
VDC 12 - 24
Refrigerant piping Not supplied
Refrigerant pipe size
(Min. wall thickness)
Liquid in 1/4 (0.0265) 3/8(0.0285)
Gas in 1/2 (0.0285) 5/8(0.0315)
Connection method
Indoor Flared
Outdoor Flared
Between the indoor &
outdoor units
Height difference ft 50 100
Piping length ft 100
Refrigerant charge (R410A) 3 lb. 9 oz. 4 lb. 14 oz.
Note: Test conditions are based on AHRI 210/240.
5DWLQJFRQGLWLRQV&RROLQJ²,QGRRUÛ)'%Û):%2XWGRRUÛ)'%Û):%
+HDWLQJ²,QGRRUÛ)'%Û):%2XWGRRUÛ)'%Û):%
3
SPECIFICATION
OPERATING RANGE
(1) POWER SUPPLY
Rated voltage Guaranteed voltage (V)
Outdoor unit
208/230 V
1 phase
60 Hz
Min. 187
208 230 Max. 253
To Next Page
