33
OCH688A
Main
Main display:
Cursor Page
Main menu
Maintenance
Initial setting
Service
F1 F2 F3 F4
Service menu
Cursor
Select:
Enter maintenance password
unem ecivreS
unem ecivreS
rosruC
rosruC
:unem niaM
:unem niaM
Test run
Input maintenance info.
Function setting
Check
Self check
Maintenance password
Remote controller check
Service menu
Service menu:
Not available.
Please stop the unit.
2
When the Service menu is selected, a window will appear asking for the pass-
word.
To enter the current maintenance password (4 numerical digits), move the
cursor to the digit you want to change with the F1
or F2 button.
Set each number (0 through 9) with the
F3
or
F4
button.
Then, press the
button.
1
Select "Service" from the Main menu, and press the button.
*At the main display, the menu button and select "Service" to make the
maintenance setting.
Maintenance password is required
Note: The initial maintenance password is "9999". Change the default
password as necessary to prevent unauthorized access. Have the
password available for those who need it.
: If you forget your maintenance password, you can initialize the
password to the default password "9999" by pressing and holding
the
F1
and
F2
buttons simultaneously for three seconds on the
maintenance password setting screen.
3
If the password matches, the Service menu will appear.
The type of menu that appears depends on the connected indoor units’ type.
Note: Air conditioning units may need to be stopped to make certain set-
tings. There may be some settings that cannot be made when the
system is centrally controlled.
A screen will appear that indicates the setting has been saved.
Navigating through the screens
• To go back to the Main menu ..................
button
• To return to the previous screen ...............
button
1
1-1-1. Selecting functions using the wired remote controller <P
AR-3xMAA
("x" represents 0 or later)>
<Service menu>
To Next Page
