TROUBLESHOOTING
1
LOSS OF POWER
Possible causes
• Propeller may be fouled. Remove propeller, clean and
replace.
• Battery connections may be corroded.
• Battery has low voltage. Recharge and check for bad cell.
• Insufficient wire gauge from battery to trolling motor.
(Six gauge wire recommended.)
• Bad or faulty connection in boat wiring or trolling motor
wiring.
• Permanent magnet cracked or chipped. Motor will whine or
grind.
• Water in lower unit that will show water or oily residue
inside top housing.
2 MOTOR MAKES EXCESSIVE NOISE OR
VIBRATION
Possible causes
• Propeller may be fouled.
• Check to see if propeller is secure.
• Bent armature. Remove propeller, set at medium speed,
turn unit on and watch armature for wobble.
• Turn propeller by hand. It should turn freely with a slight
magnet drag.
• Bearing/bushings may be worn out.
3
MOTOR FAILS TO RUN AT ANY SPEED
Possible causes
• Check fuse\circuit breaker on boat for trolling motor
• Check for loose or corroded connections
• Check plug for loose or bad connection
• Test micro, on\off, and bypass switches.
• Turn prop by hand. It should turn freely with a slight magnet
drag.
4 MOTOR LOSES ONE OR MORE SPEEDS
Possible causes
• Loose wire on rotary switch. Check wiring diagram.
• Loose connections in top housing.
• Rotary switch bad.
• Prop fouled.
• Speed coils in lower unit may be burned.
5 FOOT PEDAL IS HARD TO TURN (MECANICAL
STEER MODELS)
Possible causes
• Check to see if column is bent and binding against outer
tubing.
• Outer tube is bent and binding against column.
• Bottom bushing or bearing is out of alignment or broken.
• Check rack and rack guide for foreign matter. Remove rack,
clean, grease, and replace.
• Steering cable is kinked. Replace steering cable.
6 MOTOR DOES NOT TURN THE FULL 400 DEGREE
ROTATION (ES MODELS ONLY)
Possible causes
• Foot-pedal needs to be recalibrated.
7 ARROW BACKLIGHT IS OFF (ES MODELS ONLY)
Possible causes
• Arrow light turns off after 3 minutes of motor inactivity.
Press momentary button to turn light back on
8 HARD TO UNLATCH MOUNT FROM THE RUN OR
STOW POSITION WHEN USING PULL ROPE.
• Your bow mount is designed to easily release with a quick
pull of the rope handle. If it does not, it is almost always
due to the improper installation of your bracket. What
usually happens is that your bracket does not rest evenly
on the isolators before you tighten it down. Once
tightened, the bracket binds up, causing the latch to not
function properly. You can test this by loosening the screws
slightly (start with the two forward screws) and latching the
bracket. You will usually find the problem area by
alternately trying each screw until the bracket releases
easily. The final step is to install additional shim washers
(provided) and then re-tighten the screws.
Apply a general purpose grease to the latch pins and
grooves periodically.
REPAIR PARTS AND SERVICE
FOR REPAIR SERVICE
Contact your nearest Super Center for a listing of Super
Centers. See the listing at the back of this manual or visit our
website at www.motorguide.com.
FOR REPLACEMENT PARTS AND ORDERING
MotorGuide has established MotorGuide Super Centers as
Parts Distributors throughout the United States and Canada.
Contact the nearest Super Center for parts ordering. When
ordering replacement parts have the following information
ready:
• Model Number
• Serial Number
• Part Number
