Motorola PRO5150 User Manual

15
English
GETTING STARTED
Attaching the Belt Clip Removing the Belt Clip
1 Align the grooves of the belt clip with those of
the battery.
2 Press the belt clip downward until you hear a
click.
1 Use a key to press the belt clip tab away from
the battery.
2 Slide the belt clip upward to remove it.
2
1
Belt Clip Tab

Motorola PRO5150 Specifications

General

Channel Capacity	16 channels
Dimensions	137 mm x 57.5 mm x 37.5 mm
Operating Temperature	-30°C to +60°C
Emergency Button	Yes
IP Rating	IP54
Frequency Range	136-174 MHz, 403-470 MHz
Power Output	VHF: 5W, UHF: 4W
Weight	420 g (with battery)
Signaling	MDC1200
Battery Life	Up to 11 hours (with high capacity battery)
