Motorola XT420 User Manual

English
BATTERIES AND CHARGERS
9
Drop-in Tray Single Unit Charger LED Indicators
(*) Normally, re-positioning the battery pack will correct this issue.
(**) Battery temperature is too warm or too cold or wrong power voltage is being used.
If there is NO LED indication:
1. Check if the radio with battery, or the battery alone, is inserted correctly.
2. Ensure that the power supply cable is securely plugged into the charger socket.
3. Confirm that the battery being used with the radio is listed in Table 1.
Table 2: Charger LED Indicator
Status LED Status Comments
Power On Green for approx. 1 sec
Charging Steady red
Charge Complete Steady green
Battery Fault (*)
Red fast flash
Waiting to charge (**)
Amber slow flash
Battery Level Status
Flash red 1 time
Battery low
Flash amber 2 times
Battery medium
Flash green 3 times
Battery high

Motorola XT420 Specifications

General

Purpose	Multi-Use Radio Service (MURS)
Maximum range	- m
Operating frequency	446.00625 - 446.19375 MHz
Rechargeable	Yes
Battery life (max)	20 h
Product color	Black
Tones quantity	6
Transmit power	500 mW
International Protection (IP) code	IP55
Charger	No
Quantity	1
Operating temperature (T-T)	-30 - 60 °C

Weight and Dimensions

Depth	40 mm
Width	58 mm
Height	116 mm
Weight	244 g
