CHAPTER 2
HARDW
ARE INST
ALLA
TION
2-19
USB Connectors
The mainboard provides a
UHCI (Universal Host Controller Interface)
Universal Serial Bus root
for attaching USB devices like: keyboard, mouse
and other USB devices. Y
ou can plug the USB device directly to this
connector
.
USB Port 2
USB Port 1
PI
N
SIGNAL
1
VCC
2
-Data
3
+Data
4
GND
1 2 3 4
22
24
