5
Spécifications Spécifications
Suite du tableau de la page précédente
Moniteur
système
y Détection de la température du CPU et du système
y Détection de la vitesse du ventilateur du CPU et du système
y Contrôle de la vitesse du ventilateur du CPU et du système
Dimensions
y Format m-ATX
y 22,6 cm x 18,5 cm (8,9󾙕 x 7,3󾙕)
Fonctions BIOS
y 1 x flash BIOS 128 Mb
y UEFI AMI BIOS
y ACPI 6.1 , SM BIOS 2.8
y Multilingue
Logiciel
y Pilotes
y DRAGON CENTER
y CPU-Z MSI GAMING
y Intel
®
Extreme Tuning Utility
y Google Chrome™, Google Toolbar, Google Drive
y Norton™ Internet Security Solution
Fonctions
Dragon Center
y Hardware Monitor
y Eyerest
y Live Update
Référez-vous au site http://
download.msi.com/manual/mb/
DRAGONCENTER2.pdf pour plus
de détails.

MSI B365M PRO-VD Specifications

General

Form Factor	Micro-ATX
Chipset	Intel B365
CPU Socket	LGA 1151
Memory Slots	2
Maximum Memory	32 GB
Memory Type	DDR4
Memory Speed	2666/ 2400/ 2133 MHz
SATA 6Gb/s Ports	6
M.2 Slots	1
Audio	Realtek ALC887
LAN	Realtek 8111H Gigabit LAN
PCIe Slots	1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1
USB 3.1 Gen1 Ports	4
USB 2.0 Ports	6
Video Outputs	HDMI, VGA
