2-14
Introductions
Right Side View
1. Audio Port Connectors
Make high quality sound blaster with stereo system and Hi-Fi function supported. Connect your
speakers to the proper connectors as shown below.
Headphone out: Used for speakers or headphones.
Mic In/Line In: Used for an external microphone.
2. USB Port
The USB port allows you to connect USB-interface peripheral devices, such as the mouse,
keyboard, modem, portable hard disk module, printer and more.
1. Audio Port Connectors
2. USB Port
3. Optical Drive Device
3
1
2
To Next Page
