2-18
Introductions
Left Side View
1. Kensington Lock Hole
This notebook provides a Kensington Lock hole, which allows users to secure the notebook in
place with a key or some mechanical PIN device and attached through a rubberised metal cable.
The end of the cable has a small loop which allows the whole cable to be looped around a
permanent object, such as a heavy table or other similar equipment, thus securing the notebook
in place.
2. Power Connector
To connect the AC/DC adapter and supply power for the notebook.
3. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation.
1. Kensington Lock Hole
2. Power Connector
3. Ventilator
4. HDMI Connector
5. USB Port
6. Audio Port Connectors
6
4
1
3
2
5
To Next Page
