MSI Gaming Raider GE77HX User Manual

2-10 2-11
Introductions
Rear Side View
1. Ventilator
The ventilator is designed to cool the system. DO NOT block the ventilator for air
circulation.
2. Thunderbolt (Type-C) port
• Thunderbolt™ 4 supports USB4, PCIe, HDMI, DisplayPort connection; 8K display
monitor output; up to 40Gbps transfer rate.
• Supports maximum 5V/3A portable charging power output when AC power is
connected. However, the maximum portable charging power limitation may up to
5V/1.5A while only battery DC power is connected. (follow the Intel Thunderbolt
protocol).
3. Power Connector
This connector is to connect the AC/DC adapter and supply power for the notebook.
4. RJ-45 Connector
The Ethernet connector, with optionally supported transmitting rate of
10/100/1000/2500 megabits per second, is used to connect a LAN cable for network
connection.
5. HDMI Connector
HDMI (High-Definition Multimedia Interface) technology is the industry-leading
interface and de-facto standard connecting high-definition (HD) and ultra high-
definition (UHD) equipment.

MSI Gaming Raider GE77HX Specifications

General

Model	MSI Gaming Raider GE77HX
Processor	Intel Core i9-12900HX
Graphics	NVIDIA GeForce RTX 3080 Ti
RAM	32GB DDR5
Weight	2.9 kg
Webcam	FHD type (30fps@1080p)
Operating System	Windows 11 Home
Battery	99.9Whr
Keyboard	SteelSeries per-Key RGB keyboard
Audio	Dynaudio speakers
Networking	Killer Wi-Fi 6E, Bluetooth 5.2
Ports	1x HDMI 2.1, 1x RJ45, 1x SD card reader, 1x Audio combo jack
