2-20
Introductions
Rear Side View
1. Kensington Lock
This notebook provides a Kensington Lock hole, which allows users to secure the notebook in
place with a key or some mechanical PIN device and attached through a rubberised metal cable.
The end of the cable has a small loop which allows the whole cable to be looped around a
permanent object, such as a heavy table or other similar equipment, thus securing the notebook
in place.
2. Power Connector
To connect the AC/ DC adapter and supply power to the notebook.
2
6
1
7
3
4
5
1. Kensington Lock
2. Power Connector
3. RJ-45 Connector
4. VGA Port
5. E-SATA Connector
6. HDMI Connector
7. Ventilator
