MSI K9A2 Platinum V2 Series User Manual

2-2
MS-7376 Mainboard
DDR2 DIMMs, p.2-6
Back Panel
I/O, p.2-9
CPUFAN1, p.2-13
ATX1, p.2-8
IDE1, p.2-11
JUSB1~3,
p.2-15
SATA1~6,
p.2-12
FDD1, p.2-11
CPU, p.2-3
J1394_1, p.2-17
Quick Components Guide
JFP2, p.2-16
SYSFAN1,
p.2-13
JBAT1, p.2-18
SPDOUT1, p.2-17
JPWR1, p.2-8
JTPM, p.2-14
JFP1, p.2-16
JSLIC1, p.2-15
JAUD1, p.2-14
SYSFAN2,
p.2-13
JCOM1, p.2-16
SYSFAN3,
p.2-13
PCI Slots,
p.2-23
PCI Express
slots, p.2-20
JCD1, p.2-13
SYSFAN4,
p.2-13
JPW1, p.2-8
RESET, p.2-19
POWER, p.2-19
