3-7
BIOS Setup
[Type] Select how to define the HDD parameters
[Cylinders] Enter cylinder number
[Heads] Enter head number
[Write Precompensation] Enter write precomp cylinder
[Sectors] Enter sector number
[Maximum Capacity] Read the maximal HDD capacity
[LBA Mode] Select [Auto] for a hard disk > 512 MB un-
der Windows and DOS, or [Disabled] un-
der Netware and UNIX
[Block Mode] Select [Auto] to enhance the hard disk
performance
[Fast Programmed I/O Select [Auto] to enhance hard disk perform-
Modes] ance by optimizing the hard disk timing
[32 Bit Transfer Mode] Enable 32 bit to maximize the IDE hard disk
data transfer rate
Floppy Drive A:/B:
This item allows you to set the type of floppy drives installed. Available options: [Not
Installed], [1.2 MB 5¼], [720 KB 3½], [1.44 MB 3½], and [2.88 MB 3½].
