3-6
MS-7222 Micro-ATX Mainboard
DMA Mode
This item allows you to enable or disable the DMA (Direct Memory Access) mode.
Setting options: [Auto], [Disabled], [UDMA0], [UDMA1], [UDMA2], [UDMA3], [UDMA4],
[UDMA5].
Floppy A
This item allows you to set the type of the floppy drives installed. Available options:
[Disabled], [360 KB, 5
1/4
], [1.2 MB, 5
1/4
], [720 KB, 3
1/2
], [1.44 MB, 3
1/2
], [2.88MB, 3
1/2
].
Halt On
The setting determines whether the system will stop if an error is detected at boot.
Available options are:
[No Errors] The system doesn’t stop for any detected error.
[All, But Keyboard] The system doesn’t stop for a keyboard error.
System Information
Press <Enter> to for the sub-menu of each item:
Total Memory/BIOS Version
This item shows the memory status and BIOS version of your system (read only).
**CPU Information**
Genuine Intel (R)/CPU ID/uCode ID/CPU Frequency
The three items show the CPU related information of your system (read only).
