Hardware Setup
The motherboard provides the following buttons for you to set the computer’s function.
This section will explain how to change your motherboard’s function through the use
of button.
Buttons
Power Button: POWER1
This power button is used to turn-on or turn-off the system. Press the button to turn-
on or turn-off the system. This button will light after you power-on the system, and
the light will turn-off when you power-off the system.
Reset Button: RESET1
This reset button is used to reset the system. Press the button to reset the system.
This button will light when the system is in S0 status.
RESET1
POWER1
D-LED2 Change Menu Button: DLED2
This button is used to change the menu on D-LED2 panel. Press the button to change
the menu on D-LED2 panel. Please refer to the D-LED2 quick guide for more details
and usages.
DLED2
