MSI MS-7520 ECLIPSE Series User Manual

A-2
MS-7520 Mainboard
X-Fi Xtreme Audio Card is powered by Creative CA0110 Digital Audio Controller.
This card provides advanced audio functions by offering a comprehensive suite of
software applications. The advanced tools and amazing features provided will
allow you to experience a full array of exciting activities, such as listening to
effects enhanced music, watching a multi-channel movie, playing the latest game
or recording a high quality audio track.
Introduction
1
2
9
10
MIC _L MIC _PW R LINE out_R Front_JD LINE out_L
Ground
NC
MIC_JD
NC(No pin)
LINE out_JD
VCC
SPDIF
GND
Front Panel Audio Connector
- Pin definition
S/PDIF-Out Connector
- Pin definition
