MSI MS-7793 User Manual

En-6
MS-7793 Manboard
Back Panel Quck Gude
Mouse/Keyboard
A combnaton PS/2
®
mouse/keyboard DIN connector for a PS/2
®
mouse/keyboard.
LAN
The standard RJ-45 LAN jack s for connectng to a
Local Area Network (LAN).
LED Color LED State Condton
Left Yellow O󰘯 LAN lnk s not establshed.
On(Steady) LAN lnk s establshed.
On(󰘱ashng) The computer s communcatng wth another computer on the network.
Rght
Green O󰘯 10 Mbts/sec data rate
On 100 Mbts/sec data rate
Orange On 1000 Mbts/sec data rate
USB 2.0 Port
The USB 2.0 port s for attachng USB 2.0 devces such as keyboard, mouse, or other
USB 2.0-compatble devces.
USB 3.0 Port
USB 3.0 port s backward-compatble wth USB 2.0 devces. It supports data transfer
rate up to 5 Gbt/s (SuperSpeed).
Important
In order to use USB 3.0 devces, you must connect to a USB 3.0 port. If a USB cable s
used, t must be USB 3.0 complant.
▶
▶
▶
▶
Yellow Green/ Orange
USB 3.0 Port
LAN
Mouse/
Keyboard
USB 2.0 Port
VGA Port
HDMI Port
Optcal
S/PDIF-Out
DsplayPort
DVI-D PortUSB 2.0 Port
Lne-In
Lne-Out
Mc
RS-Out
CS-Out
SS-Out
