MSI Z170-A PRO User Manual

4
Speci󰄈cations
Continued from previous page
USB
● Intel
®
Z170 Chipset
▶ 8x USB 3.1 Gen1 (SuperSpeed USB) ports (4 ports on
the back panel, 4 ports available through the internal
USB 3.1 Gen 1 connectors)
▶ 6x USB 2.0 (High-speed USB) ports (2 ports on the back
panel, 4 ports available through the internal USB 2.0
connectors)
Audio
● Realtek
®
ALC892 Codec
● 7.1-Channel High Definition Audio
LAN 1x Realtek
®
RTL8111H Gigabit LAN controller
Back Panel
Connectors
● 1x PS/2 keyboard/ mouse port
● 1x VGA port
● 1x DVI-D port
● 1x DisplayPort
● 1x LAN (RJ45) port
● 4x USB 3.1 Gen1 ports
● 2x USB 2.0 ports
● 6x audio jacks
Internal Connectors
● 1x 24-pin ATX main power connector
● 1x 8-pin ATX 12V power connector
● 6x SATA 6Gb/s connectors
● 2x SATAe connectors
● 2x USB 2.0 connector (supports additional 4 USB 2.0
ports)
● 2x USB 3.1 Gen1 connectors (supports additional 4 USB
3.1 Gen1 ports)
● 2x 4-pin CPU fan connectors
● 3x 3-pin system fan connectors
● 1x Front panel audio connector
● 2x Front panel connectors
● 1x TPM module connector
● 1x Chassis Intrusion connector
● 1x Serial port connector
● 1x Parallel port connector
● 1x Clear CMOS jumper
I/O Controller NUVOTON NCT6793 Controller Chip
Continued on next page
