Chapter 1
1-4Getting Started
Motherboard Specications
CPU
Support
4th Generation Intel
®
Core™ i7 / Core™ i5 / Core™ i3 / Pentium
®
/
Celeron
®
processors for LGA 1150 socket
■
Chipset Intel
®
Z87 Express Chipset■
Memory
Support
4x DDR3 memory slots supporting up to 32GB
Supports DDR3 3000(OC)/ 2800(OC)/ 2666(OC)/ 2600(OC)/
2400(OC)/ 2200(OC)/ 2133(OC)/ 2000(OC)/ 1866(OC)/ 1600/ 1333/
1066 MHz
Dual channel memory architecture
Supports non-ECC, un-buered memory
Supports Intel
®
Extreme Memory Prole (XMP)
■
■
■
■
■
Expansion
Slots
3x PCIe 3.0 x16 slots
The operating mode will be x16/ x0/ x0, x8/ x8/ x0, or x8/ x4/ x4.
Please always install expansion card into the PCI_E2 “First”.
4x PCIe 2.0 x1 slots
■
-
■
Onboard
Graphics
(Z87-G55
only)
1x VGA port, supports the maximum resolution of 1920x1200 @
60Hz
1x HDMI
®
port, supports the maximum resolutions of
4096x2160@24Hz, 24bpp/ 2560x1600@60Hz, 24bpp/
1920x1080@60Hz, 36bpp
1x DVI-D port, supports the maximum resolution of 1920x1200 @
60Hz
■
■
■
Multi-GPU
Support
Supports 3-Way AMD CrossFire
TM
Technology*
Supports 2-Way NVIDIA
®
SLI
TM
Technology
* Supports Windows 7 and Windows 8.
■
■
Storage Intel Z87 Express Chipset
1x mSATA 6Gb/s port* (For Z87-G55 only)
6x SATA 6Gb/s ports (SATA1~6)*
Supports RAID 0, RAID1, RAID 5 and RAID 10
Supports Intel Smart Response Technology, Intel
®
Rapid Start
Technology and Intel Smart Connect Technology**
* The SATA6 port will be unavailable when install a SSD in the mSATA port.
** Supports Intel Core processors on Windows 7 and Windows 8.
■
-
-
-
-
USB Intel Z87 Express Chipset
6x USB 3.0 ports (4 ports on the back panel, 2 ports available
through the internal USB connectors)
8x USB 2.0 ports (2 ports on the back panel, 6 ports available
through the internal USB connectors)
■
-
-
Audio Realtek
®
ALC892 Codec
7.1-Channel High Denition Audio
Supports S/PDIF output
■
-
-
LAN 1x Realtek
®
8111G Gigabit LAN controller■
