Motherboard Speci󰘰cations
CPU
Support
4th Generation Intel
®
Core™ i7 / Core™ i5 / Core™ i3 / Pentium
®
/
Celeron
®
processors for LGA 1150 socket
■
Chipset Intel
®
Z87 Express Chipset■
Memory
Support
4x DDR3 memory slots supporting up to 32GB
Supports DDR3 3000(OC)/ 2800(OC)/ 2666(OC)/ 2600(OC)/
2400(OC)/ 2200(OC)/ 2133(OC)/ 2000(OC)/ 1866(OC)/ 1600/ 1333/
1066 MHz
Dual channel memory architecture
Supports non-ECC, un-bu󰘯ered memory
Supports Intel
®
Extreme Memory Pro󰘰le (XMP)
■
■
■
■
■
Expansion
Slots
5x PCIe 3.0 x16 slots (PCI_E1, PCI_E2, PCI_E3, PCI_E5, PCI_E7)*
The operating mode will be x0/ x16/ x0/ x0/ x0, x16/ x0/ x0/ x16/
x0, x8/ x0/ x8/ x16/ x0 or x8/ x0/ x8/ x8/ x8.*
Support for installing up to 4 PCIe x16 expansion cards.
2x PCIe 2.0 x1 slots
* For a single expansion card installation with optimum performance, using the PCI_E2 slot
is recommended.
■
-
-
■
Onboard
Graphics
2x HDMI ports, supporting a maximum resolution of
4096x2160@24Hz, 24bpp/ 2560x1600@60Hz, 24bpp/
1920x1080@60Hz, 36bpp
1x DisplayPort, supporting a maximum resolution of
4096x2160@24Hz, 24bpp/ 3840x2160@60Hz, 24bpp
■
■
Multi-GPU
Support
Supports 4-Way AMD
®
CrossFire
TM
Technology
Supports 4-Way NVIDIA
®
SLI
TM
Technology
Supports Lucidlogix
®
Virtu MVP 2*
* Supports Windows 7 and Windows 8.
■
■
■
Storage Intel
®
Z87 Express Chipset
1x mSATA 6Gb/s port*
6x SATA 6Gb/s ports (SATA1~6)*
Supports RAID 0, RAID1, RAID 5 and RAID 10
Supports Intel
®
Smart Response Technology, Intel
®
Rapid Start
Technology and Intel
®
Smart Connect Technology**
2x ASMedia ASM1061 Chipset
4x SATA 6Gb/s ports (SATA7~10)
* The SATA5 port will be unavailable when install a SSD in the mSATA port.
** Supports Intel Core processors on Windows 7 and Windows 8.
■
-
-
-
-
■
-
USB Intel Z87 Express Chipset
4x USB 3.0 ports (available through the internal USB connectors)
6x USB 2.0 ports (2 ports on the back panel, 4 ports available
through the internal USB connectors)*
2x ASMedia ASM1074 Chipset
8x USB 3.0 ports on the back panel
* Internal JUSB1 connector supports MSI Super Charger.
■
-
-
■
-
Audio Realtek
®
ALC1150 Codec
7.1-Channel High De󰘰nition Audio
Supports S/PDIF output
■
-
-

MSI Z87 XPOWER Specifications

General

Brand	MSI
Model	Z87 XPOWER
Category	Motherboard
Language	English
