Chapter 1
1-37 Getting Started
MULTI_BIOS_SWITCH1: Multi-BIOS Switch
This motherboard has two built-in BIOS ROMs (Labeled A and B, default BIOS ROM
is A). If one is crashed, you can shift to the other for booting by sliding the switch. In
addition, these two BIOS ROMs do not have the Auto Recovery feature, you need to
maintain or update the BIOS version by yourself.
A B
Blue LED
Green LED
BIOS recovery using the M-ash utility:
1. Ensure that the system is switched o.
2. Boot up the system with the operational BIOS ROM by switching the Multi-BIOS
switch.
3. Enter the BIOS setup → M-Flash → Save BIOS to storage and then save the le to
a bootable USB drive disk (root folder).
4. Switch back to the BIOS ROM that needs to be recovered.
5. Choose “Select one le to update BIOS” and recover the BIOS ROM with the le
saved in the USB pen drive.
Important
Do not use the Multi-BIOS switch when system is booting up.
