MTD "A" Series User Manual

Electric start
31
Battery removal
To remove/replace the battery:
1. Take the cover off of the battery box. See Figure 6.6.
2. Disconnect positive and negative battery leads.
See Figure 6.7.
3. Slide the charger port out of the battery box.
4. Lift the harness out of the way.
5. Lift the battery out of the battery box.
6. Install the battery by following the previous steps in
reverse order.
7. Test run the mower by following the previous steps in
reverse order.
Figure 6.6
Battery box
Figure 6.7
Positive lead
Negative lead
Charger port
Do not short the battery terminals.
! CAUTION! CAUTION
Figure 6.8
Battery
