MTS Systems Exceed 40 Series Site Preparation Guide

Load Frame Dimensions and Weight
MTS Exceed™ Series 40 Site Preparation Guide System Specifications
19
Load Frame Dimensions and Weight
The following table provides the dimensions of various load frame types. If you
transfer the load frame to its final site location after unpacking the system, then
use these dimensions to ensure that the frame fits through all doorways and
hallways.
Load Frame Dimensions
M ODEL W IDTH D EPTH H EIGHT W EIGHT
E42.503 642 mm
(25.28 in)
582 mm
(22.91 in)
1300 mm
(51.18 in)
115 kg
(254 lb)
E42.503E 642 mm
(25.28 in)
582 mm
(22.91 in)
1600 mm
(62.99 in)
125 kg
(276 lb)
E43.104 681 mm
(26.81 in)
588 mm
(23.15 in)
1617 mm
(63.66 in)
120 kg
(265 lb)
E43.104E 681 mm
(26.81 in)
588 mm
(23.15 in)
1917 mm
(75.47 in)
130 kg
287 lb)
E44.104;E44.304 845 mm
(33.27 in)
716 mm
(28.19 in)
1862 mm
(73.31 in)
435 kg
(959 lb)
E44.104E;E44.304E 845 mm
(33.27 in)
716 mm
(28.19 in)
2162 mm
(85.12 in)
450 kg
(992 lb)
E45.105 Single zone 1230 mm
(48.43 in)
870 mm
(34.25 in)
2055 mm
(80.91 in)
1400 kg
(3086 lb)
E45.105 Double zone 1230 mm
(48.43 in)
870 mm
(34.25 in)
2135 mm
(34.25 in)
1430 kg
(3152 lb)
E45.105E Single zone 1230 mm
(48.43 in)
870 mm
(34.25 in)
2355 mm
(34.25 in)
1450 kg
(3197 lb)
E45.105EDouble zone 1230 mm
(48.43 in)
870 mm
(34.25 in)
2435 mm
(34.25 in)
1480 kg
(3263 lb)
E45.305 Single zone 1215 mm
(47.83 in)
960 mm
(37.80 in)
2360 mm
(92.91 in)
1700 kg
(3748 lb)
E45.305Double zone 1215 mm
(47.83 in)
960 mm
(37.80 in)
2395 mm
(94.29 in)
1745 kg
(3847 lb)
E45.305E Single zone 1215 mm
(47.83 in)
960 mm
(37.80 in)
2660 mm
(104.72 in)
1750 kg
(3858 lb)
E45.305EDouble zone 1215 mm
(47.83 in)
960 mm
(37.80 in)
2695 mm
(106.10 in)
1795 kg
(3957 lb)
E45.605 1660 mm
(65.35 in)
1272 mm
(50.08in)
2820 mm
(111.02 in)
3500 kg
(7716 lb)
